Avionics

Rechargeable Battery Pack & Charger

	Sennheiser Electronic Corp.
	BA202-12 with NT202-120 charger
	12V 2250 mAh
	Nickel Metal Hydride
	Two available
	Plus one XLR to Cigarette adapter for HMEC350/450 (~$34)

iCom Battery Case BP-194 (~$20)

	8 x AA Case
	For F3T, F4T, A4, T2A


iCom Cigarette Lighter Cable with Noise Filter - CP-13 and CP-13L (~$40)

	L version has "L" shaped plug
	One each

FlightCom & iCom Cigarette Lighter Power Adaptor (~$12)

	Outside of plug is ~0.2" or 5.5mm
	Center pin to center pin
	No transformer or noise filter
	Six available


iCom Desktop Charger BC-119 (~$70)

Note that you will also need a battery cup to go inside this base. See the instruction sheet (.pdf)

iCom Wall Charger BM-112U (~$30)

Wall Charger for ICOM Transceivers. Works with the Icom IC-A4, IC-A5, IC-A23, IC-A6, IC-A24, IC-A20, IC-A2, IC-A22, IC-A3, and IC-A21 transceivers.

David Clark Battery Holder with Case

Part # 40654G-01


Digital Recorder

FlightCom AiRepeater (tape recorder)

	Portable, digital cockpit recorder
	Records everything you hear through your headset
	Operates on one 9-volt battery
	Installation/Operation Manual (.pdf)

Headset Adapter Cords

David Clark Helicopter to Dual GA Adapter 18253G-05 (~$80)

	Converts U-174/U or U-93A/U to M642/5-1 (PJ068) and M642/4 (PJ055).
	Also converts the Helicopter Single Plug to a Dual Plug configuration for Fixed Wing flying.
	General Aviation applications only.
	Two David Clarks and one Pilot USA, Inc. PA-75 available

David Clark Military U75/U to Civilian Headset Adapter 18253G-02 (~$80)

The U-75/U cord plug is used for some military aircraft cord and most recently for US Forest Service aircraft.

Converts U-75/U to M642/5-1 (PJ068) and M642/4-1 (PJ055)

The U-75/U mates with the U-61/U jack

Wiring:

	Microphone High to Pin 1
	Earphone High to Pin 2
	Microphone Low (and shield) to Pin 3
	Earphone Low to Pin 4

Three Available

David Clark Civilian Headset to Military U75/U Adaptor (JB-19) (~$85)

This adapter converts a GA headset which has a .206" mic and .25" phone plug into one which uses a military U-175/U plug. 9" in length. (Standard to U-175/U)

Icom OPC-782, A22 to A5 Speaker & Mic Connector Plug (~$16)

	Mini Plugs
	Two available


Low to High Impedance Headset Adapter (~$70)

	Converts a low impedance mic and phone military headset into higher impedance for use in general aviation aircraft.
	It also converts the U174/U plug on the military headset into .206" and .25" plugs used in general aviation.
	3' in length.
	Two available

FlightCom IIsx Expansion Cord (~$4)

Six available

David Clark DC Dual Plug Coil Cord (~$100)

	P/N 40602G-01
	Connects ENC Battery Powered Module to Dual Radio jacks in GA Aircraft
	Wiring Diagram Schematic (.pdf)



Exp Module AC-2XM (~$50)

For A2-EX ICS

Push to Talk Adapter

More than just your standard headset plugs

Telex PEV-77 Earset (~$75)

	N.O. 61563020
	2 oz
	Single magnetic reciever
	Built-in Volume controls for 10dB range
	6' coiled cord

Dual Microphone "Y" Adapter Cable (~$30)

	By Pilot USA Inc. PA-74
	2 ft
	One microphone male plug Ys into two female microphone plugs

Headphone Earpiece Equipment

David Clark Foam Filled Ear Seals (~$5)

	Part No. 18316G-02 (on box) 18316G-01 (on ear-cup)
	Soft, dependable foam-filled ear seals provide a perfect fit that is both comfortable and secure.
	Not for H20-10 standard and ENC Models.



David Clark Pillow Earseal - Foam Filled

	Part No. 18691G-03
	For Headsets: H3341, H3441, H3531, H6041, H7041, H8740

David Chart Flo-Fit Gel Earseals

	for H20-10X Series
	P/N 40243G-10

David Clark Stop Gap Eyeglass Cushions

P/N 12500G-02



Misc. Items

Belt Clip for Radio

	7/8" between holes
	1 1/4 wide x 2 7/8 long

Garmin StreetPilot GPS Swivel Base Mount

	P/N 010-10199-02
	Affixes to your car's dash for quick and easy mounting of the StreetPilot's cradle mount. (incuded with separate purchase of StreetPilot).
	It allows your StreetPilot's ccradle mount to easily lock into place and pivot 360�.
	Low profile sleek design fits conveniently to your vehicle's dash with permanent or non-permanent adhesive putty disk.

David Clark Mounting Kit for Expansion Module Model 200EX

	P/N 40318G-05
	This bracket will mount the 200EX intercom box (picture on right)

Megatech DC Peak Detection Battery Charger (~$10)

Link

FEATURES:

	PEAK DETECTION CHARGING CIRCUITRY FOR OPTIMUM CHARGING EVERY TIME
	LED CHARGING STATUS INDICATOR
	INPUT: 12V DC
	OUTPUT: 6-8.4V
	CAPACITY: 250-900MAH

NiMH Battery & wall Charger

	FlyZone by Hobbico
	HCAM7111 MiMH Battery for Sky Screamer R/C
	HCAP9911 AC Wall Charger
